Capacities 1/2 to 85 metric tons, grade 6
Working Load Limit and grade '6' permanently shown on every shackle
Forged — Quenched and Tempered, with alloy pins
Hot Dip galvanized or self coloured. (85, 120, and 150 metric ton shackles are all hot dip galvanized bows and the bolts are Dimetcoted® and painted red)
Sizes 3/8'' and below are mechanically galvanized
Fatigue rated (1/2t - 55t)
Shackles 25t and larger are RFID EQUIPPED
Approved for use at -40° C (-40 degrees F) to 204° C (400° F)
Meets or exceeds all requirements of ASME B30.26
Sizes 1/2 - 25t meet the performance requirements of EN13889:2003
Shackles 55 metric tons and smaller can be furnished proof tested with certificate to designated standards, such as ABS, DNV, Lloyds, or other certification when requested at time of order
Type Approval certification in accordance with ABS 2016 Steel Vessel Rules and 2016 ABS Guide for Certification of Lifting Appliance available. Certificates available when requested at time of order and may include additional charges
All 2150 shackles can meet charpy requirements of 42 Joules (31 ft/lbf) avg at -20° C (-4° F) upon special request
Look for the Red Pin® . . . the mark of genuine Crosby quality.
